Y82S Small Vertical Baler

The Small Vertical Baler features a vertical design, occupying minimal space longitudinally, allowing it to be flexibly installed in narrow corners. It is perfectly suited for small recycling centers and workshops with limited space.

Inquire Now
  • Product Description
  • Product Features
  • Specifications

Product description

Usage

Specially used for compressing the waste like food residue, paper, bottles, cans, plastic scraps and textile waste etc. The compact machine body ensures it only require less installation space, which is the favor of the vessels, hotels, resorts and factories etc. Bottom liquid receiver is optional for collecting the liquid from the compressing materials.

Product Features

● Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine
● Bottom liquid receiver is optional for collecting the liquid from the compressing materials
● The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation
● Equipped with independent emergency stop for safe operation
● Equipped with Euro and U.S standard anti-rebound gate structure which makes sure the safety of operation
● Special ram guides design makes the platen not slope because of uneven materials feedings during compression
● Equipped with NOK seals that from Japan means longer lifespan of the seals
● Equipped with A.M.C. oil pipe joints that from Japan ensures the machine far away from oil leakage problems
● Equipped with integrated valves that from Taiwan, conveniently for the maintenance
● Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which replacing the common coupling connection so that extend the lifespan of the pump

Specifications

ModelY82S-10AY82S-20AY82S-30D
(Twin Chamber Baler)
Pressure10tons20tons30tons
Feed Opening Size(L*H)600*400mm700*400mm700*500mm
Baling Chamber Height1000mm1200mm728mm
Bale Size(L*W*H,
H is adjustable)
600*400*(200-600)mm800*600*(400-800)mm700*500*(150-400)mm
Bale Weight20-50kgs60-120kgs30-60kgs
Power2.2kw3kw0.75KW
Machine Weight800kgs1000kgs500kg
Machine Overall Dimension900*570*2240mm1180*800*2550mm1600*560*1750mm
